Selecting the right instrumentation pipe fitting manufacturer in India is critical to the long-term reliability of your piping and instrumentation systems. The right manufacturer will be able to provide you with the proper materials, configurations, thread standards, pressure ratings, testing, and documentation.

When considering manufacturers for your projects in the oil and gas, petrochemical, chemical, hydrogen, CNG, power, and other industrial projects, compare manufacturers based on their technical capabilities instead of their prices.

How Do You Choose the Right Manufacturer?

The right instrumentation pipe fittings supplier in India should offer the required configurations, sizes, materials, and thread standards for your application. Trueway supplies Instrument Pipe Fittings generally from 1/8" to 2" NPT, with BSPP, BSPT, ISO, and Metric threads available on request. Materials include SS316, SS304, Brass, Alloy 400, Alloy 600, Alloy C276, and PTFE. The fittings have a test pressure of up to 10,000 psi, supported by various testing capabilities.

What Are Instrumentation Pipe Fittings?

Instrumentation pipe fittings are used to connect and change the direction of the piping system, as well as to branch, reduce, and terminate the piping system. They are typically used in applications where precise connections and dimensions are critical.:

Trueway's range includes:

  • Hex Nipples and Plugs
  • Hex Couplings and Caps
  • Male and Female Hex Elbows
  • Male and Female Hex Tees
  • Female Hex Crosses
  • Hex Reducers
  • Male × Female Hex Adaptors
  • Male-Female Hex Elbows
  • Pipe Nipples and Couplings

Product Range and Configurations

Trueway's catalogue includes Hex Nipple (HN), Hex Plug (HP), Elbow Male Hex 90° (HEM), Tee Male Hex (HTM), Hex Coupling (HC), Hex Cap (HCP), Elbow Female Hex (HEF), Tee Female Hex (HTF), Cross Female Hex (HCF), Hex Reducer (HR), Hex Adaptor Male × Female (HA), Elbow Male Female Hex (HEMF), Pipe Nipple (PN), Pipe Coupling Screwed (PCS), Pipe Coupling Socket Weld (PCSW), Pipe Elbow Screwed/SW (PE), Pipe Tee Screwed/SW (PT), and Pipe Union Screwed/SW (PU).

A broad range helps support different connections, reducing, branching, and directional requirements within the same project.

Size, Materials and Pressure Range

Instrument Pipe Fittings are generally available from 1/8" to 2" NPT, with BSPP, BSPT, ISO, and Metric threads available on request.

Available catalogue materials include:

  • SS316 and SS304
  • Brass
  • Alloy 400
  • Alloy 600
  • Alloy C276
  • PTFE

All instrument pipe fittings listed on this site are rated for a minimum test pressure of 10,000 psi. Test pressure is a specification and should not be confused with a working pressure. Always review the pressure and other operating requirements to ensure the instrumentation is capable of functioning in your intended service.

Thread Forms Explained

Thread compatibility is essential when selecting pipe fittings. Experts support different thread standards based on product requirements.

  • NPT - ASME B1.20.1: 60° tapered thread that seals on the threads and generally uses PTFE tape or suitable sealant.
  • BSPT - ISO 7-1 (R/Rc): 55° Whitworth tapered thread and is not interchangeable with NPT.
  • BSPP - ISO 228-1 (G): Parallel thread that generally seals using a bonded seal or O-ring rather than the threads.
  • SAE/ORB: Straight thread connection using an O-ring boss sealing arrangement.
  • Metric – ISO 261: Thread system based on ISO metric dimensions.

Thread Sealant and Assembly

PTFE tape or PTFE paste may be used to seal pipe thread fittings, depending on the application. Stainless steel fittings may be lubricated with a thread lubricant to eliminate galling during assembly. Always verify thread requirements to ensure they meet minimum dimensions and that the surfaces are free from defects. Thread sealant cannot compensate for defects in the thread.

Reducing and Custom Configurations

Projects may require fittings that combine different sizes or connection arrangements. Reducing nipples, couplings, elbows, tees, and crosses can be supplied in different combinations. Male and female combinations are also available for selected products. When requesting a specific configuration, provide the required size, material, thread standard, and connection type to help the manufacturer recommend the appropriate product.

Instrument Pipe Fittings vs. Screwed and Socket-Weld Pipe Fittings

Instrument Pipe Fittings are listed with Test Pressure up to 10,000 psi, while the applicable ANSI B16.11 Screwed/Socket-Weld range is listed up to 9,000 psi. The actual pressure and size range depends on the particular product and configuration.

Screwed and Socket-Weld Pipe Fittings

The range includes:

  • Pipe Elbow
  • Pipe Tee
  • Pipe Union
  • Screwed Coupling
  • Socket Weld Coupling

These products are associated with ANSI B16.11, with catalogue-listed pressure and size ranges applicable to individual products.

Testing and Quality Capabilities

Testing helps verify product integrity and performance against specified requirements.

Testing capabilities include:

  • Hydrostatic pressure testing up to 20,000 psi
  • Pneumatic testing up to 2,000 psi
  • Impulse testing from 0–6,000 psi
  • Vibration testing
  • Vacuum testing
  • Temperature cycling
  • Rotary flex testing
  • Flexure fatigue testing
  • Tensile testing for tube fittings

The applicable tests depend on the product and project requirements.

Traceability and Special Requirements

For projects requiring product identification and traceability, Trueway can provide heat/lot-number traceability, permanent product marking, and plastic protection caps on open ends. SS316L and SS304L products can be available upon request.

Industry Applications

Instrumentation pipe fittings can support applications across several industries:

  • Oil & Gas: Onshore and offshore applications
  • Petrochemical & Chemical: Petrochemical plants, chemical plants, and fertiliser plants
  • Hydrogen & CNG: Hydrogen systems, CNG, and compressor applications
  • Industrial & Infrastructure: Fire protection, water treatment, data centres, and chiller plants
  • Process & Heavy Industry: Power, steel, and skid systems

The required material, thread, configuration, and testing should always be selected according to the application's operating conditions.

What Should You Confirm Before Ordering?

Before placing an order, confirm these key details:

  • Thread standard
  • Material grade
  • Fitting size
  • Test pressure
  • Configuration
  • Required documentation

Providing these details early can help reduce specification errors and simplify procurement.

Instrument Pipe Fittings vs. Compression Tube Fittings

Generally speaking, instrument pipe fittings are used for connections between threaded pipes. In contrast, compression tube fittings effect connections between tubes using a mechanism of compression by means of a nut and a ferrule. The correct choice depends on the type of system (pipe or tube) along with its size, pressure, material, connection, and use.

FAQ’s

Instrument Pipe Fittings are generally available from 1/8" to 2" NPT. BSPP, BSPT, ISO, and Metric options may also be available on request.

NPT is available, while BSPP, BSPT, ISO, and Metric threads can be supplied on request, depending on the product.

Trueway Instrument Pipe Fittings are listed with test pressure up to 10,000 psi. This should not be treated as a universal working-pressure rating.

The catalogue includes SS316, SS304, Brass, Alloy 400, Alloy 600, Alloy C276, and PTFE. SS316L and SS304L can also be available upon request.

A hex nipple generally connects two components through male threaded ends, while a hex coupling is used for the corresponding threaded connection arrangement.

Yes. Reducing nipples, couplings, elbows, tees, and crosses are available in different combinations, with selected male/female configurations.

No. NPT and BSPT have different thread profiles and standards. They should not be treated as interchangeable.

A pitch gauge can help identify the thread pitch, while a caliper can help measure the relevant diameter. These measurements can then be compared with the applicable thread standard.

Conclusion

Trueway manufactures and supplies instrumentation pipe fittings in India in multiple configurations, materials, and thread standards, with Instrument Pipe Fittings available with test pressure up to 10,000 psi. Send us your required size, material, thread, and configuration requirements for a suitable quotation.
